Chario


AVIATOR BALBO

3 WAY CENTER CHANNEL


The Aviator line center speaker has been created to be a simple, elegant, and performing solution for the home systems. Versatile and powerful, Balbo speaker is able to perform the thumping bass of a movie, or the pristine mids and highs of a female vocalist. Born as a center speaker Balbo grant all the performances usually provided by a 3 way speaker, rising the level of your system and increasing the listening experience

IL DESIGN NON È SOLO QUELLO CHE APPARE E SI PROVA. IL DESIGN È COME FUNZIONA


IDEAS

Center Channel is the part of the system that has to be really in line with the rest of it. Balbo is the natural extension of the Aviator Line to fullfil the need in order to have a proper multichannel System.

PRESENTED: 2019

 TWEETER: 1x T38 WG

WOOFER: 2 x 130 mm Hz

Technical Data

CONFIGURATION

3-way Reversed Array

DRIVERS

1 Tweeter 38mm T38Waveguide
2 Woofer 130 mm ROHACELL® Full-Apex™ Poly-Ring NdFeB motor

SENSITIVITY

90 dB SPL normalized to 1 m/2.83 Vrms/ de-correlated L/R pink noise in ITU-R BS 1116-1 compliant listening room

LOW FREQUENCY CUT OFF

58 Hz @ -3 dB referred to C4 WETS

CROSSOVER FREQUENCIES

Midwoofer-Tweeter Crossover @ 1850Hz
Woofer-Tweeter Crossover @ 1300Hz

SUGGESTED AMPLIFIER

Up to 120W/4Ω Average Power

RATED IMPEDANCE

Modulus 4Ω (minimum 3.9Ω @185Hz) More than +36° (500-1200Hz)

LOW FREQUENCY LOAD

Back-Firing Vented

EAR LISTENING HEIGHT

Preferably on woofer axis

FINISHING

Solid walnut and hdf

SIZE

189 x 558 x 310 mm (H x W x D)

WEIGHT

12 Kg ( single piece )

SPEAKER ORIENTATION

Speakers should be titled inward facing the listener

LISTENING DISTANCE & LAYOUT

Minimum speaker-listener distance  2.0 m A carpeted floor in front of the speakers is recommended

WARRANTY

5 years Worldwide

SPARE PARTS AVAILABILITY

All the spare parts will be available for 15 years after the model will be discontinued.
