MP-150

NAGAOKA · MP

MP-150

Dynamic performance and refined clarity for the serious vinyl enthusiast.

The Nagaoka MP-150 stands as a significant performance step within the MP series, balancing energetic dynamics with a refined, liquid presentation. By employing high-quality materials and precise manufacturing, it bridges the gap between everyday listening and true high-end fidelity. At the heart of the MP-150 is a hardened, tapered aluminium cantilever paired with a superfine elliptical diamond stylus. This configuration allows for exceptional traceability, ensuring that complex passages are handled with ease while maintaining a smooth and fatigue-free character across the frequency spectrum. The sound signature is defined by its firm, muscular bass and a full, rich midrange. It avoids the clinical sharpness found in lesser designs, choosing instead to present music with a natural warmth and a wide, cohesive soundstage that brings both jazz and rock recordings to life.

Key Features

01

Hardened Tapered Aluminium Cantilever

This low-mass, high-rigidity design ensures rapid transient response and accurate groove tracking.

02

Superfine Elliptical Diamond Stylus

A precision-polished elliptical tip provides superior detail retrieval and extended frequency response.

03

Samarium Cobalt Magnet

Utilises a powerful magnetic material to ensure a consistent, high-output signal with exceptional clarity.

04

Anti-Ferro Magnetic Permalloy Shielding

The casing is designed to shield the internal motor from electromagnetic interference, resulting in a cleaner noise floor.

Engineering Precision

Chapter 01

Engineering Precision

Nagaoka's commitment to mechanical integrity is evident in the MP-150. By using a reinforced carbon fibre pole shoe and precise permalloy shielding, the design eliminates unwanted vibrations and electrical noise, allowing the cartridge to extract every nuance from the record groove.
Listening Notes

Chapter 02

Listening Notes

The MP-150 delivers a sound that is both punchy and composed. It is particularly adept at handling rhythmic drive, making it a stellar choice for jazz, vocal performances, and classic rock. Expect a wide soundstage and a deep, tuneful bass response that remains tight without ever feeling forced.

Specifications

TypeMoving permalloy (MM)
Frequency response20Hz – 20kHz
Sensitivity4.5mV (1kHz, 5cm/sec)
Impedance47k ohms
Cartridge Weight6.5g
Channel separation24 dB (1 kHz)
Channel balance1.5 dB or less
Load capacitance100 pF
CantileverHardened tapered aluminum alloy
Needle tip0.4×0.7mil ellipse/diamond
Appropriate needle pressure1.5~2.0g
Weight16.5g
