NAT Audio · Vacuum Tube Power Amplifiers
Se Evo
Pure single-ended triode performance refined for the modern reference system.
The Se Evo stands as the latest evolution of a design legacy spanning over two decades, representing the most refined implementation of single-ended amplification in the current NAT Audio catalogue. By removing all passive components from the signal path between the input and the output transformer, the design achieves a level of directness that allows the source signal to maintain its integrity without artificial coloration.
At the heart of the Se Evo is a proprietary linear field output transformer, which provides the versatility required to drive a wide array of loudspeakers with precision. Unlike conventional single-ended designs, the unit maintains exceptional stability and tonal linearity regardless of fluctuations in line voltage, thanks to a sophisticated regulated power supply for both high voltage and filament stages.
Sonically, the amplifier avoids the common pitfalls of over-damped or overly lush tube designs. It presents music with a rare combination of transient speed, harmonic density, and rhythmic authority. The result is a presentation that feels immediate and present, allowing the listener to perceive both the structural complexity and the nuanced shading of a performance without editorialising the output.
Key Features
01
Direct signal path
The design eliminates all coupling capacitors and inter-stage transformers to preserve signal purity.
02
Linear field output transformer
A proprietary transformer design ensures exceptional compatibility and control across varying speaker impedances.
03
Regulated power supply
Dedicated regulation for high voltage and filament stages maintains consistent performance regardless of line fluctuations.
04
Paper-in-oil energy storage
Incorporates a high-energy US NOS paper-in-oil capacitor to support the regulated power supply.

Chapter 01
Engineering Purity
The Se Evo follows a uncompromising philosophy of simplicity. By ensuring the signal travels through the circuit without encountering coupling components, the amplifier achieves a high degree of transparency. This approach reflects the brand's long-standing dedication to removing the mechanical barriers between the recording and the listener.

Chapter 02
Listening Notes
The Se Evo delivers a performance that prioritizes microdynamic shading and temporal accuracy. It avoids the romanticised, slow character often associated with lesser single-ended designs, instead offering a rhythmic, percussive quality that anchors the soundstage. It is a tool for those who require total honesty from their amplification.
Specifications
TypeSingle-ended monoblock power amplifier
Frequency response8 Hz to 75 kHz
Sensitivity1 V RMS
ImpedanceInput: 100 kohms
Power handling25 W @ 1 kHz
Dimensions (H × W × D)260 mm × 483 mm × 400 mm
Weight41 kg per unit
Finish optionsBlack or silver
